Pipe Cooling Tank PL Series
Pipe Cooling Tank Details
Features:
304 stainless steel tank, stainless steel cover plate
Nozzle head make high-speed spray vortex to reach good cooling performance
With water level control and water temperature control system
Application of European PE filters
Can provide different length of tank according to customer pipe size range
Adjustable supporting rollers to be suitable for different pipe sizes
Main parameter:
|
Model
|
Working range (mm)
|
Tank length (mm)
|
Tank thickness (mm)
|
Water pump
(kW)
|
Tank style
|
Central height
(mm)
|
|
PL-63
|
16-63
|
5800
|
2
|
3
|
Cover plate Structure
|
1000-1050
|
|
PL-110
|
20-110
|
5800
|
2
|
4
|
1000-1050
|
|
|
PL-160
|
50-160
|
5800
|
2
|
4
|
1000-1050
|
|
|
PL-250
|
90-250
|
5800
|
2
|
4
|
1000-1050
|
|
|
PL-315
|
90-315
|
5800
|
2
|
5.5
|
1000-1050
|
|
|
PL-450
|
110-450
|
5800
|
2
|
5.5
|
Tempered glass sliding door structure
|
1100-1150
|
|
PL-630
|
250-630
|
5800
|
2
|
7.5
|
1100-1150
|
|
|
PL-800
|
400-800
|
5800
|
2
|
7.5
|
1200-1250
|
|
|
PL-1000
|
500-1000
|
5800
|
3
|
7.5
|
1400-1450
|
